732.14.100 0,1bar (100mbar) 2 x G 1/2 female lower mountPN 40 barCase material: Stainless steel 316SSclass 1.6Permissible medium temperature: -20 ... +100 °C (-4 ... +212 °F)Pressure Gauge Standard: International (standard Europe)stop pin at 6 o'clock*WIKA* Serial number *...*Label: WIKA standard without / with Tag-number

S-20 ; 0 ... 10 bar gauge; 4 ... 20 mA, 2-wire @ DC 8...35 V Pressure transmitter Model S-20 Non-linearity: 0.25% BFSL Overpressure limit: 2 times Process connection: G 1/2 B EN 837 ; Sealing: copper Pressure port: D 2.5 mm Electrical connection: angular connector DIN 175301-803 A mating connector included pin assignment el. connection: U+=1, U-=2 Permissible medium temperature: -30...+100°C shock and vibration resistance: 100 g shock, 20 g vibration Leakage rate: 5x10^-3 (mbar*l)/s Approvals: cULus Test protocol: with test protocol

732.51.100 100 mbar 2 x G 1/4 femaleConnector location: lower mountmax. static pressure: 6 barOverpressure safety: 2,5 barclass 1.6venting of pressure chamberIngress protection: StandardPermissible medium temperature: -20 ... +100 °C (-4 ... +212 °F)Pressure Gauge Standard: International (standard Europe)*WIKA*

PSD-4; 0 ... 16 bar gauge ; two switching outputs (PNP/NPN) Electronic pressure switch with display Output signal: two switching outputs (PNP/NPN) IO-Link: without Power supply: 15...35 V DC Measuring range: 0 ... 16 bar gauge Process connection: G 1/4 A DIN EN ISO 1179-2 Sealing: NBR Media temperature: -20 … 85 °C (-4 ... +185 °F) El. connection: Circular connector M12x1 (4-pin) pin assignment el. connection: U+=1, U-=3, SP1=4, SP2=2 Accuracy: ± 0.5% of span Approvals: cULus with test protocol Specifications according to data sheet: PE 81.86

PSD-4; 0 ... 10 bar gauge ; two switching outputs (PNP/NPN) Electronic pressure switch with display Output signal: two switching outputs (PNP/NPN) IO-Link: without Power supply: 15...35 V DC Measuring range: 0 ... 10 bar gauge Process connection: G 1/4 A DIN EN ISO 1179-2 Sealing: NBR Media temperature: -20 … 85 °C (-4 ... +185 °F) El. connection: Circular connector M12x1 (4-pin) pin assignment el. connection: U+=1, U-=3, SP1=4, SP2=2 Accuracy: ± 0.5% of span

S-20 ; 0 ... 10 bar gauge; 4 ... 20 mA, 2-wire @ DC 8...35 V Pressure transmitter Model S-20 Non-linearity: 0.25% BFSL Overpressure limit: 2 times Process connection: G 1/4 A DIN EN ISO 1179-2 ; Sealing: NBR Pressure port: D 2.5 mm Electrical connection: angular connector DIN 175301-803 A mating connector included pin assignment el. connection: U+=1, U-=2 Permissible medium temperature: -20...+100°C shock and vibration resistance: 100 g shock, 20 g vibration Approvals: cULus
